DJI Matrice 4TD: Industrial Thermal Drone for Dock Deployment

Overview
The Matrice 4TD is DJI’s rugged industrial-grade thermal imaging drone built for permanent deployment and autonomous 24/7 operations with the DJI Dock 3. A fixed-arm airframe, IP55 weatherproofing, and operating range of -30°C to 50°C make it the right tool for extreme field conditions.

Multi-Sensor Payload
The M4TD carries a 20MP wide-angle camera, 48MP medium tele, 48MP telephoto, and a 640×512 uncooled thermal camera (f/1.0 VOx microbolometer) in one integrated unit. A laser range finder measures targets up to 1,800 m and an NIR auxiliary light covers up to 100 m for night operations.

Autonomous 24/7 Operations
Paired with DJI Dock 3, the Matrice 4TD supports fully automated missions at up to 47 minutes of flight time. Data transmits live up to 25 km via D-RTK 3 Relay. FlightHub 2 handles cloud-based mission planning, scheduling, and log management.

Key Specs

• Flight time: 47 min
• Wind resistance: 12 m/s (Level 6)
• Operating temp: -30°C to 50°C
• Thermal: 640×512 uncooled VOx, f/1.0
• Transmission: 25 km (D-RTK 3 Relay)
• Obstacle detection: wire-level (12 mm)
• IP rating: IP55
• Compatible: DJI Dock 3 / RC Plus 2 Enterprise

Replaces the DJI Matrice 3TD (End of Supply May 2026).
